AMD Ryzen 7 7700X CPU, AM5, 4.5GHz (5.4 Turbo), 8-Core, 105W (142W Turbo), 40MB Cache, 5nm, 7th Gen, Radeon Graphics, NO HEATSINK/FAN

Please note the Turbo TDP and ensure you use an adequate cooler for this CPU.

The Dominant Gaming Desktop Processor

Lead your team to victory with the top 8-core AMD gaming processor.

When you have the world’s most advanced processor for designers and content creators, the possibilities are endless. Whether you are designing the next skyscraper or animating a complex character, you need a powerful processor that can handle your workflow's full spectrum of computing demands.

Hands down, the AMD Ryzen 7000 Series desktop processors set the bar for performance-seeking artists and engineers alike.

Key Specifications

• Socket: AM5
• Type: AMD Ryzen 7
• Clock Speed: 4.5 GHz
• Turbo Speed: 5.4 GHz
• Cores: 8 Core
• Threads: 16

Core and Cache Details

• Core Size:

  • CPU Cores: TSMC 5nm FinFET
  • I/O Die: TSMC 6nm FinFET

• Cache:

  • L1 Cache: 512KB
  • L2 Cache: 8MB
  • L3 Cache: 32MB

Power and Cooling

• TDP:

  • 105W
  • 142W Turbo

• Cooler: No

Integrated Graphics

• Graphics: Yes
• Graphics Details:
  • AMD Radeon Graphics
  • Graphics Cores: 2
  • Frequency: 2200 MHz
  • GPU Base: 400 MHz
  • USB Type-C DisplayPort Alternate Mode support

Memory Support

• Memory Channels: 2

• Max Memory: 128GB

• System Memory Subtype: UDIMM

• Max Memory Speed:

  • 1x1R: 5200 MT/s
  • 1x2R: 5200 MT/s
  • 2x1R: 3600 MT/s
  • 2x2R: 3600 MT/s

PCI Express Lanes

• Max PCI Express Lanes: 28/24 (Total/Usable)

Additional Usable PCIe Lanes from Motherboard:

• AMD X670E: 12x Gen4
• AMD X670: 12x Gen4
• AMD B650E: 8x Gen4
• AMD B650: 8x Gen4

Special Features

• AMD EXPO Technology
• AMD Ryzen Technologies

Packaging Details

• Package Type: Retail
• Package Weight: 0.1150 kg
