Asus ROG MAXIMUS Z790 DARK HERO, Intel Z790, 1700, ATX, 4 DDR5, HDMI, Thunderbolt 4, Wi-Fi 7, 2.5G LAN, PCIe5, Polymo Lighting, 5x M.2

Unmatched Performance and Compatibility

The ROG Maximus Z790 Dark Hero is engineered for robust cooling, WiFi 7, and ample PCIe 5.0 slots, delivering unmatched performance. It is fully compatible with 14th Gen Intel® Core™ processors, ensuring cutting-edge capability for your system.

Stealthy Design with Polymo Lighting

Its sleek and stealthy design is enhanced by the innovative Polymo lighting, which illuminates the I/O shroud with a microstructural array of dual-layer RGB, adding a personalized and stylish touch to your gaming setup.

Key Features at a Glance

• PCIe 5.0: Includes 1 onboard M.2 slot and 2 PCIe 5.0 x16 slots.
• DDR5 Memory: Supports up to 192GB, featuring DIMM Flex and AEMP II.
• WiFi 7: Next-gen wireless technology for ultra-fast speeds.
• AI Overclocking: Effortless performance boost with intelligent tuning.
• AI Cooling II: One-click fan tuning for optimal thermal and acoustic balance.
• 20+1+2 Power Stages: Teamed power solution for stable performance.
• DIY-Friendly Design: Simplifies building and customization.
• Polymo Lighting: Adds a touch of brilliance to your build.
• Thunderbolt™ 4: Advanced connectivity for modern devices.

Advanced Cooling and Overclocking

AI Overclocking

Tuning is faster and smarter than ever. ASUS AI Overclocking profiles your CPU and cooling system to predict the optimal configuration, allowing you to push your system to its limits. Engage predicted values automatically or use them as a starting point for further customization.

AI Cooling II

Achieve perfect thermal and acoustic balance with a single click. A proprietary ASUS algorithm reduces unnecessary noise during a quick stress test and dynamically adjusts fan speeds based on CPU temperatures.

Next-Gen Connectivity

WiFi 7

The next-gen WiFi 7 chipset offers ultrawide 320 MHz channel bandwidth and 4096 QAM, delivering speeds up to 2.4X faster. The innovative Multi-Link Operation (MLO) ensures stable connections and lower latency for gaming, streaming, and industrial IoT.

2.5GB Ethernet

Enjoy low-latency gaming, speedy file transfers, and high-resolution video streaming with onboard Intel® 2.5 Gbps Ethernet.

AI Networking

GameFirst optimizes network performance by allocating bandwidth in real time, now integrated into Armoury Crate for a seamless experience. It includes support for NVIDIA® GeForce NOW, ensuring minimal latency during intense cloud gaming sessions.

Expanded Aesthetics with Aura Sync

Elevate your gaming setup with Aura Sync lighting. Synchronize preset lighting effects across compatible ROG graphics cards, monitors, keyboards, and mice for a unified, visually stunning aesthetic.

Technical Specifications

• Motherboard Type: Desktop
• Form Factor: ATX
• Socket: Intel 1700
• Chipset: Intel Z790
• Maximum Memory: 192GB (DDR5)
• RAM Slots: 4 x DIMM, up to 8000+(OC) speeds
• Graphics Ports: 1 x HDMI, 2 x Intel Thunderbolt 4 (USB Type-C)
• PCI/PCI Express: 2 x PCIe 5.0 x16, 1 x PCIe 4.0 x4
• Storage: 4 x SATA III, 5 x M.2 slots (PCIe 5.0 and 4.0 support)
• Wireless: Intel Wi-Fi 7, Bluetooth v5.4
• LAN: 2.5GB Ethernet
• Audio: ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
• USB Ports:
  • Rear: 2 x Thunderbolt 4, 6 x USB 10Gbps, 4 x USB 5Gbps
  • Front: 1 x USB 20Gbps, 4 x USB 5Gbps, 4 x USB 2.0

Accessories Included

• 1 x ARGB RGB extension cable
• 4 x SATA 6Gb/s cables
• 1 x Thermal pad for M.2
• 1 x DDR5 fan holder
• 1 x ASUS WiFi Q-Antenna
• 3 x M.2 backplate Q-Latch packages
• 3 x M.2 backplate Rubber Packages
• 1 x Q-connector
• 1 x ROG stickers
• 1 x ROG key chain
• 1 x M.2 rubber package
• 1 x ROG VIP card
• 1 x USB drive with utilities and drivers
• 1 x Quick start guide

Package Details

• Type: Retail
• Weight: 4.2000 kg
