THE MOST COLORFUL WAY TO COOL
DUAL CHAMBER
LOW-PROFILE DUAL CHAMBER
The PPS (Polyphenylene sulfide) and glass fiber construction resists a broad range of chemicals
and is unaffected by moisture or immersion in water.
Our pump is light and impervious to oxidation and corrosion.
STYLISH RADIATOR
Custom design low resistance radiator allows higher flow rate, heat exchange efficiency and provides unmatched cooling performance
DOUBLE TUBING
FEP tubing makes it durable yet flexible. Sleeved tubing on the exterior to give it a premium look.
AIR BALANCE FANS
Aside from having perfect balance of airlfow and airpressure to exhaust air through the fins and out of the case, the dual fans uses an silent driver IC that smoothens fan operation to reduce fan clicks and vibrations.
Weight & dimensions | |
Weight | 1.68 kg |
Package weight | 2.55 kg |
Package depth | 440 mm |
Package height | 275 mm |
Package width | 139 mm |
Radiator width | 39.4 cm |
Radiator depth | 11.9 cm |
Radiator height | 2.72 cm |
Fan dimensions (W x D x H) | 120 x 120 x 25 mm |
Pump width | 8.36 cm |
Pump depth | 7.18 cm |
Pump height | 5.27 cm |
Energy management | |
Pump voltage | 12 V |
Fan voltage | 12 V |
Packaging content | |
RGB controller included | |
Other features | |
Country of origin | China |
Design | |
Product colour | Black |
Number of fans | 3 fan(s) |
Illumination colour | Blue, Green, Red |
Fan connector | 4-pin |
Radiator material | Aluminium |
Illumination LED | |
Performance | |
Type | All-in-one liquid cooler |
Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2011-v3 (Socket R), LGA 2066, LGA 775 (Socket T), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+ |
Suitable location | Processor |
Maximum airflow | 66.7 cfm |
Maximum air pressure | 2.34 mmH2O |
Fan speed (max) | 2000 RPM |
Fan speed (min) | 650 RPM |
Fan noise level (min) | 6 dB |
Fan noise level (max) | 30 dB |
Pump noise level | 15 dB |
Pulse-width modulation (PWM) support | |
Pump connector | 3-pin |
Pump's mean time to failure (MTTF) | 70000 h |
Fan's mean time to failure (MTTF) | 160000 h |
Logistics data | |
Master (outer) case height | 315 mm |
Master (outer) case width | 457 mm |
Master (outer) case length | 575 mm |
Products per master (outer) case | 4 pc(s) |
Harmonized System (HS) code | 84733080 |
EAN | 4719512071007 |
