Fractal Design Adjust Pro Fan Speed & ARGB Lighting Hub, Up to 16 ARGB Devices, Presets, Animation Modes, Startup Effects, No Software Needed

Adjust Pro Hub Features

Key Features:

• RGB and fan speed customization without the need for background software.
• Easily configurable via Fractal’s online Adjust Pro configuration tool.
• Customize RGB with presets, animation modes, and startup effects.
• Includes custom flat cables for easy cable management and connectivity.
• Four output ports for seamless device integration.
• Backwards compatibility with standard ARGB/PWM components via a legacy device splitter cable.
• Supports ARGB Gen 2 (backwards compatible).
• Compatible with Windows 11 “Dynamic Lighting.”
• Status LED indicator to show the state of the device.
• Grippy rubber feet and magnetic fastening ensure a firm fit in your case.
• Works out of the box.

Connect to Adjust Pro

The Adjust Pro Hub offers control and customizability of fans and RGB components without requiring background software. With backward compatibility and the ability to connect Momentum fans out of the box, this hub acts as a bridge between components and Fractal's intuitive web-based configuration tool.
Simply visit the web address for the configuration tool to:

• Modify fan speeds.
• Customize RGB settings with presets, animation modes, and startup effects.

Advanced Lighting

Customize the lighting of up to 16 ARGB Gen 2 components with:

• Dynamic themes.
• Animation modes.
• Startup effects.

Airflow Control

Effortlessly adjust your fan speed curve preferences through your web browser for optimized cooling and noise management.

Smooth Connectivity

Enjoy plug-and-play connectivity with compatible devices via:

• Four integrated device ports.
• The included legacy splitter cable.

Easy Installation

Mount the Adjust Pro Hub almost anywhere in your system using:

• Magnetic fastening.
• Rubber feet for firm and flexible placement.

Local Storage

Save all your settings locally on the Adjust Pro Hub device. No need to download or run background software.

Technical Specifications

Type:

Fan Hub

Inputs:

• 4-pin PWM Connector
• Micro-USB

Outputs:

• 4 Output Channels supporting up to 16 ARGB Gen 2 devices (4 per channel).
• Maximum LEDs: 400 combined total across all 4 channels.
• Output Connector: Proprietary USB-C.
• Legacy Splitter Cable: Proprietary USB-C to 4-pin PWM/3-pin ARGB header.

Compatibility:

• Connect Fractal Momentum fans out of the box.
• Connect ARGB/PWM devices via the included legacy splitter cable.

Fan Controller:

PWM

Installation:

• Fastening: Magnetic fastening and grippy rubber feet for firm placement.
• System Requirements: PC with available internal USB 2.0 header, Chromium-based web browser, SATA power cable from PSU.

Colour:

Black

LED Lighting:

• ARGB Gen 2
• Access advanced lighting customization with dynamic themes, animation modes, and startup effects.

Software:

• Adjust Pro intuitive, web browser-based configuration tool.
• All preferences saved locally on the device, eliminating the need for software.

Weight:

61 g

Dimensions:

90 x 53 x 17 mm

Power:

• Input Power: SATA (12V + 5V).
• Max Output Current: 12V DC - 2A / 5V DC - 4.5A.

Additional Features:

• Plug-and-play functionality.
• Local storage for saving settings directly on the hub.
• Daisy chaining support for larger setups.
• LED indicator for device status.
• Custom flat cables for clean cable management.
• Supports Windows 11 “Dynamic Lighting.”

Package Contents:

• Adjust Pro Hub
• 2 x Extension cables (500mm male-to-female Fractal Connect cables).
• 2 x Legacy splitter cables (150mm male Fractal Connect to male 4-pin PWM/3-pin ARGB header).
• 1 x USB Cable (500mm USB to motherboard cable).
• 1 x PWM Cable (500mm PWM cable).
• User manual

Package Type:

Retail

Package Weight:

0.2620 kg
